Epson - EB-805F

Supplier Product Code:
V11H923653
Full HD Laser Ultra Short Throw 3LCD Laser Projector, 5000 Lumens, 2500000:1, 20000 Hours, iProjection App, No Mount
RRP $4,799.00 inc GST
To purchase this item, please login to your Alloys account.
  • Overview
  • Key Specifications
  • Warranty

This laser display solution brings informative signage to life and produces scalable projections of up to 130 inches. It brings a fresh dimension to signage with borderless images and projection onto ultra-wide surfaces, including glass and curved walls. The EB-805F features Full HD 1080p image quality and delivers powerful and informative displays for retail, hospitality and visitor attractions. Epson's advanced laser technology is robust and reliable, providing a fit-and-forget digital signage solution. It offers bright and vivid colours in a cost-effective solution that's capable of large display sizes.

The EB-805F enables scalable display sizes of up to 130 inches, in Full HD resolution with 5,000 lumen brightness and 3LCD technology for bright colours and high display quality even in bright spaces.

Users can benefit from multi-projector and daisy-chain support for built-in edge blending, or illuminate an entire wall with one huge image. Also, the split screen feature allows users to connect multiple input sources to display different content sources simultaneously. It can be mounted on the wall, ceiling, floor, or even hidden away to create added mystery. Its ultra-short-throw design enables projection of large images from a short distance. A white version is also available.


  • Ultra-short-throw signage projector: Compact, unobtrusive design
  • Up to 130-inch display: Full HD resolution, 5,000 lumen brightness and 3LCD technology
  • Fit and forget reliability: Low maintenance laser projector with a 5 year warranty
  • Easy installation 360 degree rotation with portrait projection support
  • Flexible playback play content directly from a USB stick
  • Flexible playback options
  • Versatile and easy to install
  • Innovative and cost effective
  • Large and scalable images
  • Technical Specifications
    Brightness 5000 Lumens
    Compatibility Document Camera
    Contrast Ratio 2500000:1
    Display Color 10 Bits
    Height 0.2500
    Image Size 65 - 130 inches
    Keystone Adjustment Manual V: ± 3 Deg; Manual H:± 3 Deg
    Lens F= 1.5
    Light Source Laser Diode
    Light Source Life 20000 hours; 30000 hours (Economy)
    Native Aspect Ratio 16:9
    Net Weight 9.4 kg
    Operating Temperature 10 - 60 Deg C
    Picture and Video Color Modes Blackboard; Cinema; Dynamic; Presentation; sRGB
    Power Consumption 366 Watt, 262 Watt (economy), 0.5 Watt (standby)
    Power Supply AC 220 - 240V, 50/60 Hz
    Projection Offset 9:1
    Projection System 3LCD; RGB liquid crystal shutter
    Resolution Support Full HD
    Speaker 8 Watt
    Throw Ratio 0.27 - 0.37 (Wide, Tele)
    Throw Type Ultra Short
    Vertical Scan Rate 192 - 240 Hz
    Weight 24.8500
    Width 0.5700
    Length 0.6600
    Resolution 1080p
    Brand Epson
    Dimensions 45.8 W x 21 H x 37.5 D cm
    Interface USB 2.0; 802.11a/b/g/n/ac; VGA in (2x); VGA out
    Zoom Digital zoom; Factor: 1 - 1.35
    Warranty Information
    3 Year Warranty included
