LG 98" UH5Q Series 4K UHD Large Screen Signage Display
24/7 Commercial Display Powered by webOS™ Platform
Maximize your visual impact with the LG UH5Q Series 98-inch commercial signage display. Engineered for continuous 24/7 operation, this massive 4K UHD display combines breathtaking clarity, a sleek design, and the powerful webOS platform to deliver seamless, uninterrupted communication in retail, corporate offices, and public spaces.
Key Features
4K UHD Resolution & Striking Visuals
Experience stunningly lifelike imagery. With a native 3,840 × 2,160 (UHD) resolution and a 98-inch ADS panel, your content achieves maximum visibility and color depth (1.07 Billion colors).
Clear Visibility with 25% Anti-Glare Coating
Bright ambient lighting and reflections are no match for this display. Featuring a specialized 25% Haze anti-glare surface treatment and a robust 500 nit brightness level, text and graphics remain perfectly crisp and legible from any viewing angle ($178^\circ \times 178^\circ$).
High-Performance webOS™ Platform
Powered by webOS 6.1, this smart signage solution features an intuitive Graphical User Interface (GUI) and streamlined developer tools. Effortlessly manage apps, schedule localized content, or run multiple tasks simultaneously without requiring an external media player.
Slim, Sophisticated Design
Featuring a uniform, symmetric 18 mm even bezel and a slim 68.6 mm depth, this display allows for a tight, clean installation to the wall. The minimalist design enhances the room's decor while providing a completely immersive viewing experience.
Versatile Multi-USB & Connectivity Options
Equipped with dual USB 2.0 ports and 3 HDMI inputs (HDCP 2.2), the UH5Q enables versatile multi-tasking. Users can comfortably operate on-screen presentations while downloading PPT files from external storage or navigating with a connected mouse and keyboard.
Advanced Enterprise Integration & Reliability
-
Conformal Coating: The power board is protected against dust, iron powder, and humidity, ensuring longevity in diverse environmental conditions.
-
Smart Automation: Built-in temperature, auto-brightness, and acceleration (gyro) sensors allow the display to optimize its output dynamically based on its environment and physical orientation.
-
Eco & Safety Certified: Meets strict EMC Class B and FCC standards for safe electromagnetic emissions, while featuring a Smart Energy Saving mode that reduces power consumption by up to 70%.
Technical Specifications
| Feature |
Specification |
| Screen Size |
98 inches |
| Panel Technology |
ADS (Direct Backlight) |
| Native Resolution |
$3,840 \times 2,160$ (4K UHD) @ 60 Hz |
| Brightness / Contrast |
500 nits (Typ.) / 1,200:1 (Typ.) |
| Operation Hours |
24 Hours / 7 Days |
| Orientation |
Portrait & Landscape Support |
| Internal Memory |
8 GB (5.52 GB System + 2.48 GB Available) |
| Connectivity |
3x HDMI In, 2x USB 2.0, RS-232C (In/Out), RJ45 LAN, Audio Out |
| Wireless |
Built-in Wi-Fi & Bluetooth |
| Audio |
Built-in Speakers (10W x 2) |
| Dimensions (W x H x D) |
2,198.9 × 1,254.6 × 68.6 mm |
| Weight (Head Only) |
53.6 kg |
| VESA™ Interface |
$800 \times 400$ mm |
Software Ecosystem
-
SuperSign CMS & Cloud: An integrated, intuitive content management solution for organizing, scheduling, and deploying creative digital signage across your network. (SuperSign software licenses sold separately).
-
LG ConnectedCare: Supports real-time monitoring and remote diagnostic services to maximize hardware uptime.
-
Cisco & Crestron Connected® Certified: Seamlessly integrates with professional AV control systems and video conferencing equipment for automated workplace collaboration.
What's in the box: LG UH5Q Commercial Display, Remote Controller, Power Cord, Phone to D-Sub9 Gender Cable, Regulation Book. (Optional Wall Mount available separately).
