RQ7 Series offers built-in geometric adjustment tools, including a point-based Free Grid function to correct localized screen distortion. It ships with preactivated upgrade kit licenses for Geo Pro software. These comprise the ET-UK20 Geometry Manager Pro Software Upgrade Kit, which expands functionality and adds sophisticated line, shape, and bitmap masking tools, and the ET-CUK10 Auto Screen Adjustment Upgrade Kit, which automates edge-blending including brightness, color, and black level adjustment via a camera.
Note: Visit PASS to register your projector and download free Geometry Manager Pro software for Windows®. Compatible cameras comprise Nikon D5200/D5300/D5500/D5600/D7500. Other conditions apply. Please visit PASS for more information.
Contrast Sync and Shutter Sync via LAN Cable Only
Traditionally, Dynamic Contrast control operated individually for each projector in a multi-screen system, leading to step noise in blends due to variations in the Average Picture Level (APL). Panasonic’s Contrast Sync resolves this issue by using the average APL of all projectors in the system, resulting in a seamless multi-screen image. The RQ7 Series is the first Panasonic projector to support Contrast Sync via LAN cable only, eliminating the need for a serial cable connection and reducing system complexity. Additionally, the shutter timing of all sub-projectors is synchronized with the main projector via the LAN connection, ensuring cohesive fade-in/fade-out effects across the entire projection.
Import and Save Custom Test Patterns
In addition to 10x built-in test patterns, users can import and save 4x custom images in JPEG, BMP, or PNG format to an RQ7 Series projector via its Web Control UI or USB memory device for use as test patterns, start-up logos, and no-signal screensavers. Installers can calibrate projectors using client content or custom images without connecting to a media source device.
Note: This function replaces Logo Transfer Software.
Quickly Find the Projection Angle with Angle Monitor
RQ7 Series supports 360° projection angles, enabling image mapping on floors, walls, and 3D objects. However, aligning the projection angle with the design simulation can be challenging and requires two people. The projectors feature a built-in gyro sensor detecting changes in the projector’s pitch and roll angles, graphically displayed in the OSD settings menu. Installers can adjust the projection angle without needing assistance.
Note: The displayed values are based on the results of angle sensor detection and may differ from the actual projection angle. They are for reference only, and accuracy is not guaranteed.
Refreshed Web Control User Interface
RQ7 Series supports 360° projection angles, enabling image mapping on floors, walls, and 3D objects. However, aligning the projection angle with the design simulation can be challenging and requires two people. The projectors feature a built-in gyro sensor detecting changes in the projector’s pitch and roll angles, graphically displayed in the OSD settings menu. Installers can adjust the projection angle without needing assistance.
Note: The displayed values are based on the results of angle sensor detection and may differ from the actual projection angle. They are for reference only, and accuracy is not guaranteed.
Eco-Friendly Innovation with Proven Reliability and Recycled Materials.
Dust-Resistant Optical Engine
RQ7 Series’s optical engine and laser light source conform to the IP5X Dust Protected (IEC 60529)1 standard. This eliminates the need for a filter and enables 20,000 hours2 of maintenance-free projection. Reliability is proven by accelerated dust-chamber testing in significantly dustier conditions than those in which some competitive products are tested.
Eco Boost Maintains Perceived Brightness with Reduced Consumption
A new Eco Boost mode further reduces energy consumption when Dynamic Contrast is enabled while maintaining perceived brightness.
Note: Graphic is simulated for illustrative purposes only.
Reducing Environmental Impact with Recycled Materials
In addition to using responsibly procured materials, the plastic parts in the main projector body contain about 73%1 recycled resins, reducing the utilization of virgin materials. By supporting eco-friendly manufacturing processes and pursuing recycling-based programs at end-of-life, your organization helps minimize environmental impact throughout the product’s lifecycle.
1 By weight of the total mass of plastic parts in the projector main unit. Excludes projection lenses, printed circuit boards, labels, cables, connectors, electronic components, color sensor cases, optical components, ESD components, EMI component adhesives, and coatings.
