| Camera Type |
Bullet |
| Image Sensor |
1/2.8″ Progressive CMOS |
| Maximum Video Resolution (Megapixels) |
8 |
| Maximum Video Resolution |
3840 x 2160 |
| Frames Per Second (FPS) |
25 |
| Lens |
8 – 32 mm (H.FOV: 14 to 40°) |
| Lens Type |
Motorised Zoom |
| Maximum Night IR Distance (M) |
80 |
| LED |
Warm White & IR |
| Video Compression |
H.265+, H.265, H.264+, H.264, MJPEG |
| ONVIF depends on firmware version |
ONVIF (Profile S/G/T/M) 21.12 or greater, HTTP API |
| Accessories |
IV2422X |
| Outdoor Use |
Yes |
| IP Rating |
IP67 |
| IK Rating |
IK10 |
| Day/Night Mode |
Auto |
| Image Enhancement |
Flip mode, Brightness, Contrast, Saturation, Sharpness, Hue, Mirror, Angle Flip, Back Light, White Balance, Shutter, Time Exposure, Defog, 3D Noise Reduction |
| Intelligent Video (IVS) |
Cross Counting, Crowd Density Detection, Heat Map, Human & Vehicle Detection, License Plate Detection, License Plate Recognition, Line Crossing Detection, Perimeter Intrusion Detection, Queue Length Detection, Rare Sound Detection, Stationary Object Detection, Face Recognition |
| Licence Plate Recognition Speed |
< 120km/h |
| Edge Recording microSD/SDHC Card |
Micro SD/SDHC Card |
| Multiple Streams (encode format) |
3 Streams |
| Software |
Device Search/Config Tool, Surveillance Client (CMS/VMS), Mobile app (QR code) |
| Protocols |
IPv4/IPv6, TCP/IP, UDP, HTTP, HTTPS, DHCP, FTP, SMTP, UPnP, DNS, DDNS, NTP, PPPOE, RTP/RTSP, SNMP, SMTP, P2P (QR Code), RS-485, Wiegand |
| Language |
English, French, Spanish, Portuguese, German, Italian, Greek, Danish, Finnish, Russia, Hebrew, Turkish, Bulgarian, Arabic, Korean, Japanese, Thai, Hindi, Romanian, Dutch, Polish |
| Cloud option (camera only) |
Dropbox |
| Audio Streaming |
Yes (microphone and speaker included) |
| Ethernet |
Ethernet (10/100 Base-T) |
| Power Over Ethernet |
Yes |
| Power Supply |
Power over Ethernet IEEE 802.3af, DC12V |
| Power Consumption |
< 13W |
| Connectors |
RJ-45, DC Power Input, Analog Video Output, Audio In, Audio Out, Alarm in or out *2, Reset Button, RS-485, Wiegand |
| Operating Environment |
-35～+60°C/less than ≤ 90% RH |
| In The Box |
Free Software available from FTP, Printed quick user guide, installation template, mounting screws and plugs |
| Product Dimensions (H x W x L) mm |
135 x 135 x 354 |
| Packaging Dimensions (H x W x L) mm |
160 x 160 x 400 |
| Weight (Net) kg |
1.50 |
| Weight (Gross) kg |
2.00 |
| Warranty |
3 Year Warranty |
