Camera Type |
Panoramic |
Image Sensor |
1/2.7″ Progressive CMOS |
Maximum Video Resolution (Megapixels) |
8 |
Maximum Video Resolution |
3840 X 2160 |
Frames Per Second (FPS) |
30 |
Lens |
2.8mm (180°) |
Lens Type |
Panoramic |
Maximum Night IR Distance (M) |
30 |
LED |
IR, Red & Blue, Warm White |
Video Compression |
H.265+, H.265, H.264+, H.264, MJPEG |
ONVIF depends on firmware version |
ONVIF (Profile S/G/T) |
Accessories |
IV2422X, IV2433X, IV2444X, IV2455X, IV2457X, IV2477X |
Outdoor Use |
Yes |
IP Rating |
IP67 |
Vandal Resistant |
Yes (IK10) |
Day/Night Mode |
Day, Night, Auto, Schedule |
Image Enhancement |
Rotate, Saturation, Brightness, Contrast, Sharpness, White Balance, BLC, 3D DNR, HLC |
Intelligent Video (IVS) |
Motion Detection, Face Recogniton, Pedestrian & Vehicle Detection, Line Crossing, Object Detection, Cross Counting, Heat Map, Crowd Density, Queue Length, License Plate Recognition, Intrusion, Region Entrance, Region Exiting |
Edge Recording microSD/SDHC Card |
Micro SD/SDHC Card |
Multiple Streams (encode format) |
3 Streams |
Software |
Device Search/Config Tool, Surveillance Client (CMS/VMS), Mobile app (QR code) |
Protocols |
TCP/IP, HTTP, DHCP, DNS, DDNS, RTP/RTSP, SMTP, NTP, UPnP, SNMP, HTTPS, FTP, PPPoE |
Language |
English, French, Spanish, Portuguese, German, Italian, Greek, Danish, Finnish, Russia, Hebrew, Turkish, Bulgarian, Arabic, Korean, Japanese, Thai, Hindi, Romanian, Dutch, Polish |
Cloud option (camera only) |
Dropbox |
Audio Streaming |
Yes (microphone and speaker included) |
Ethernet |
Ethernet (10/100/1000 Base-T) |
Power Over Ethernet |
Yes |
Power Supply |
Power over Ethernet IEEE 802.3at, DC12V |
Power Consumption |
< 14W |
Connectors |
RJ-45, DC Power Input, Reset Button |
Operating Environment |
-30ºC to 60ºC (-22ºF-149ºF) Humidity: ≤90% RH |
In The Box |
Free Software available from FTP, Printed quick user guide, Installation template, Mounting screws and plugs |
Product Dimensions (H x W x L) mm |
127 x 136 x 136 |
Packaging Dimensions (H x W x L) mm |
150 x 150 x 150 |
Weight (Net) kg |
0.80 |
Weight (Gross) kg |
0.50 |
Warranty |
3 Year Warranty |
