| Image Sensor |
1/1.7″ Progressive CMOS |
| Maximum Video Resolution (Megapixels) |
12 |
| Maximum Video Resolution |
4000 x 3000 |
| Lens |
2mm (H.FOV 360°) |
| Lens Type |
Fixed |
| Maximum Night IR Distance (M) |
5 |
| Image clarity |
3 |
| Connectors |
RJ-45 , Analog Video Out, Audio In, Audio Out, Alarm in or out *4 |
| Video Compression |
H.265, H.265 |
| ONVIF (depends on firmware version) |
ONVIF( Profile S, Profile G) |
| Operating Environment |
-30～+55°C/less than ≤ 95% RH |
| Dimensions |
Ø120 X 55mm |
| Weight (Net) |
0.4 |
| Power Supply |
Power over Ethernet IEEE 802.3af, DC12V |
| Power Consumption |
<7W |
| Connectors (web) |
RJ-45 , Analog Video Out, Audio In, Audio Out, Alarm in or out *4 |
| Outdoor Use |
Yes |
| IP Rating |
IP66 |
| Vandal Resistant |
Yes |
| Frame Rate at Resolution |
25 (at 9MP) |
| Day/Night Mode |
Auto |
| Image Enhancement |
Fisheye ceiling/desktop/wall/tilt, VR, cylinder, Panorama 180, Panorama 360, 4PTZ, Fisheye+3PTZ, Fisheye+8PTZ, 3 Panorama 360 PTZ, 8 Panorama 360 PTZ, Rotate, Flip mode, Brightness, Contrast, Saturation, Sharpness, Hue |
| Edge Recording slot microSD/SDHC Card |
Yes |
| Video Compression |
H.265, H.264 (3 streams) |
| Audio Streaming |
Yes (microphone and speaker included) |
| Protocols |
TCP/IP, UDP, HTTP, HTTPS, DHCP, FTP, RTP/RTSP, DNS, DDNS, NTP, PPPOE, UPNP, SMTP, SMTP, P2P (QR code) |
| Software |
Device Search/Config Tool, Surveillance Client (CMS/VMS), Mobile app |
| Power Over Ethernet |
Yes |
| Ethernet |
Ethernet (10/100 Base-T) |
| UPNP |
Yes |
| In The Box |
Free Software available from FAQ, Printed quick user guide, Installation template, Mounting screws and plugs |
| Warranty |
3 Year Warranty |
