Poly Edge B30 IP Phone and PoE-enabled
Sleek design meets quality audio at an affordable price. Easy-to-use illuminated keys, plug-and-play provisioning, and reliability make it pure value.
Crisp audio
Hear every nuance of your call. Poly HD voice and Poly Acoustic Fence technologies give you business-grade audio quality with reduced background noise.
Easy to use
Simplicity right out of the box. No need to guess if you are on mute, speakerphone, or headset [1]. These keys light up when selected. Instantly add co-workers to your call with 5-way local audio conferencing.
Totally turnkey
Poly cloud management software makes these phones the smart choice. IT can easily monitor, manage, and maintain devices securely from the cloud with PDMS-SP and Poly Lens software.
KEY SPECIFICATIONS
|
Audio
|
Poly HD Voice; Full-duplex handsfree speakerphone with acoustic echo cancellation and background noise suppression; Individual volume settings with visual feedback for each audio path; Voice activity detection; Comfort noise generation; DTMF tone generation (RFC 2833 and in-band); Low delay audio packet transmission; Adaptive jitter buffers
|
|
Audio codecs
|
G.711 (A-law and μ-law); G.722; G.729AB; iLBC; OPUS
|
|
Certifications and compliances
|
AS/NZS 60950-1; Australia RCM; Brazil ANATEL; CAN/CSA C22.2 No. 62368-1-14EN 60950-1; CE Mark; CISPR22 Class B; EN 60950-1 & EN 62368-1; EN55024; EN55032 Class B; EN61000-3-2, EN61000-3-3; FCC Part 15 (CFR 47) Class B; ICES-003 Class B; IEC 60950-1 & IEC 62368-1; NZ Telepermit; ROHS compliant; Saudi Arabia CITC; So. Africa ICASA; UAE TRA; UL 60950-1 and UL 62368-1; VCCI Class B; China RoHS 2; ENERGY STAR; Indonesia SDPPI; Mexico NOM ANCE; Russia CU
|
|
Color
|
Black
|
|
Country of origin
|
Made in China
|
|
Display size (diagonal)
|
7.1 cm (2.8")
|
|
ECCN
|
5A992
|
|
Energy star certified
|
ENERGY STAR® certified
|
|
Headset and handset compatibility
|
Compatible with commercially available TTY adapter equipment; Compliant with ADA Section 508 Subpart B 1194.23 (all); Hearing aid compatibility to ITU-TP.370 and TIA 504A standards; Hearing aid compatible (HAC) handset for magnetic coupling to hearing aids
|
|
Headset ports
|
1 RJ-9; 1 3.5 mm headset jack; 1 Electronic Hook Switch (EHS) with optional APD-80 adapter
|
|
HTS code
|
8517180020
|
|
Management Software
|
Poly Lens; Poly Zero Touch Provisioning; Polycom Device Management Service for Service Providers (PDMS-SP) Cloud Management; Web UI to device IP address
|
|
Manufacturer product number
|
2200-49825-025
|
|
Manufacturer Warranty
|
Poly standard one-year limited warranty
|
|
Material Type for item
|
FERT
|
|
Multiple order quantity
|
10
|
|
Network protocols, supported
|
Administrator password protected; DHCP VLAN discovery; LLDP-MED for VLAN discovery; FTP/TFTP/HTTP/HTTPS server-based central provisioning; Hardware diagnostics; Manual or dynamic host configuration protocol (DHCP) network setup; Network address translation support for static configuration and Keep-Alive; QoS Support — IEEE 802.1p/Q tagging (VLAN), Layer 3 TOS, and DHCP; Status and statistics reporting; Syslog Event Logging; Conforms to IEEE802.3-2005 (Clause 40) for physical media attachment; Conforms to IEEE802.3-2002 (Clause 28) for link partner auto-negotiation; Time and date synchronization using SNTP; SIP signaling; RTCP and RTP support; IPv4; Provisioning and call server redundancy support; TCP; DNS-SRV; UDP
|
|
Operating humidity range
|
5 to 95%
|
|
Operating temperature range
|
0 to 40°C
|
|
Package dimensions (W x D x H)
|
17.6 x 16.3 x 4.4 cm
|
|
Package weight
|
300 g
|
|
Panel technology
|
Monochrome LCD
|
|
Ports
|
2 RJ-45 (10/100/1000BASE-TX Mbps)
|
|
Power
|
Built-in auto sensing IEEE 802.3af Power over Ethernet (Class 2)
|
|
Registration required
|
No
|
|
Security management
|
802.1X Authentication and EAPOL Media encryption via SRTP; Digest authentication; HTTPS secure provisioning; Encrypted configuration files; Password login; Transport Layer Security (TLS); Support for signed software executables
|
|
Special features
|
Unicode UTF-8 character support; Adjustable desk stand (2 positions); Wall mountable
|
|
Storage temperature range
|
-40 to 70°C
|
|
Telephony and call handling features
|
16 line keys (configurable, with pagination); 4 context-sensitive soft keys; 4 line keys with LED; 4 way navigation key cluster with center Select key; Anonymous call indication; Background Firmware Updates (TR-69 support); Block anonymous call; Busy Lamp Field (BLF); Call forward on busy, on no answer, unconditional; Call logs (200); Call progress tone generation; Call return; Call timer and call waiting; Call transfer, hold, divert (forward), park, pickup; Caller ID enable/disable; Daylight savings time support — worldwide; Dialing from call logs; Distinctive incoming call treatment/call waiting; Distinctive ringtones; Do not disturb function; Electronic hook switch capable; Enhanced call park; Headset select key (illuminated when selected); Hold and transfer keys; Home and back feature keys; Local five-way audio conferencing; Message Waiting Indicator (MWI); One-touch speed dial, redial; Page Groups (10); Remote missed call notification; Repeat dialing; Shared call/bridged line appearance; Speed Dialing (99 entries, E.164 or URI); Call hold/resume, diversion (forward), transfer (consultation, blind), pickup; Calling, called, connected party identification; Call logs (missed, received, placed); 4 lines displayed
|
|
UNSPSC code
|
43191511
|
|
VoIP features
|
Up to 16 SIP line registrations with pagination key
|
|
What's in the box
|
Console; Desk stand/wall mount hardware; Handset with handset cord; Network (LAN) cable; Safety information sheet; Setup sheet with QR code to documentation and video; Power supply unit (PSU)
|
[1] Most software-enabled features must be supported by the service provider platform. Please contact your IP PBX/softswitch vendor or service provider for a list of supported features.
[2] External universal AC/DC adapter, 5 VDC, 3 A, 15 W (sold separately).
